Add hf list 15 (#754)
authorpwpiwi <pwpiwi@users.noreply.github.com>
Wed, 16 Jan 2019 08:54:19 +0000 (09:54 +0100)
committerGitHub <noreply@github.com>
Wed, 16 Jan 2019 08:54:19 +0000 (09:54 +0100)
and refactoring: move all of hf list code to cmdhflist.c

client/cmdhf.c
client/cmdhf.h
client/cmdhflist.c
client/cmdhflist.h
client/cmdsmartcard.c
common/protocols.h

index 744a95d298e6d9c1b8516781e9c6672718a089f3..f11c5b651aee2d8da34658f7152d012190cc34e4 100644 (file)

 #include "cmdhf.h"

-#include <stdlib.h>
-#include <stdio.h>
-#include <string.h>
+#include "usb_cmd.h"
 #include "comms.h"
-#include "util.h"
 #include "ui.h"
-#include "iso14443crc.h"
-#include "parity.h"
-#include "cmdmain.h"
 #include "cmdparser.h"
 #include "cmdhf14a.h"
 #include "cmdhf14b.h"
@@ -31,8 +25,6 @@
 #include "cmdhfmfp.h"
 #include "cmdhfmfu.h"
 #include "cmdhftopaz.h"
-#include "protocols.h"
-#include "emv/cmdemv.h"
 #include "cmdhflist.h"
 #include "cmdhffido.h"

@@ -45,509 +37,6 @@ int CmdHFTune(const char *Cmd)
   return 0;
 }

-/**
- * @brief iso14443B_CRC_check Checks CRC in command or response
- * @param isResponse
- * @param data
- * @param len
- * @return  0 : CRC-command, CRC not ok
- *          1 : CRC-command, CRC ok
- *          2 : Not crc-command
- */
-
-uint8_t iso14443B_CRC_check(bool isResponse, uint8_t* data, uint8_t len)
-{
-       uint8_t b1,b2;
-
-       if(len <= 2) return 2;
-
-       ComputeCrc14443(CRC_14443_B, data, len-2, &b1, &b2);
-       if(b1 != data[len-2] || b2 != data[len-1]) {
-               return 0;
-       } else {
-               return 1;
-       }
-}
-
-/**
- * @brief iclass_CRC_Ok Checks CRC in command or response
- * @param isResponse
- * @param data
- * @param len
- * @return  0 : CRC-command, CRC not ok
- *             1 : CRC-command, CRC ok
- *          2 : Not crc-command
- */
-uint8_t iclass_CRC_check(bool isResponse, uint8_t* data, uint8_t len)
-{
-       if(len < 4) return 2;//CRC commands (and responses) are all at least 4 bytes
-
-       uint8_t b1, b2;
-
-       if(!isResponse)//Commands to tag
-       {
-               /**
-                 These commands should have CRC. Total length leftmost
-                 4     READ
-                 4 READ4
-                 12 UPDATE - unsecured, ends with CRC16
-                 14 UPDATE - secured, ends with signature instead
-                 4 PAGESEL
-                 **/
-               if(len == 4 || len == 12)//Covers three of them
-               {
-                       //Don't include the command byte
-                       ComputeCrc14443(CRC_ICLASS, (data+1), len-3, &b1, &b2);
-                       return b1 == data[len -2] && b2 == data[len-1];
-               }
-               return 2;
-       }else{
-               /**
-               These tag responses should have CRC. Total length leftmost
-
-               10  READ                data[8] crc[2]
-               34  READ4               data[32]crc[2]
-               10  UPDATE      data[8] crc[2]
-               10 SELECT       csn[8] crc[2]
-               10  IDENTIFY  asnb[8] crc[2]
-               10  PAGESEL   block1[8] crc[2]
-               10  DETECT    csn[8] crc[2]
-
-               These should not
-
-               4  CHECK                chip_response[4]
-               8  READCHECK data[8]
-               1  ACTALL    sof[1]
-               1  ACT       sof[1]
-
-               In conclusion, without looking at the command; any response
-               of length 10 or 34 should have CRC
-                 **/
-               if(len != 10 && len != 34) return true;
-
-               ComputeCrc14443(CRC_ICLASS, data, len-2, &b1, &b2);
-               return b1 == data[len -2] && b2 == data[len-1];
-       }
-}
-
-
-bool is_last_record(uint16_t tracepos, uint8_t *trace, uint16_t traceLen)
-{
-       return(tracepos + sizeof(uint32_t) + sizeof(uint16_t) + sizeof(uint16_t) >= traceLen);
-}
-
-
-bool next_record_is_response(uint16_t tracepos, uint8_t *trace)
-{
-       uint16_t next_records_datalen = *((uint16_t *)(trace + tracepos + sizeof(uint32_t) + sizeof(uint16_t)));
-
-       return(next_records_datalen & 0x8000);
-}
-
-
-bool merge_topaz_reader_frames(uint32_t timestamp, uint32_t *duration, uint16_t *tracepos, uint16_t traceLen, uint8_t *trace, uint8_t *frame, uint8_t *topaz_reader_command, uint16_t *data_len)
-{
-
-#define MAX_TOPAZ_READER_CMD_LEN       16
-
-       uint32_t last_timestamp = timestamp + *duration;
-
-       if ((*data_len != 1) || (frame[0] == TOPAZ_WUPA) || (frame[0] == TOPAZ_REQA)) return false;
-
-       memcpy(topaz_reader_command, frame, *data_len);
-
-       while (!is_last_record(*tracepos, trace, traceLen) && !next_record_is_response(*tracepos, trace)) {
-               uint32_t next_timestamp = *((uint32_t *)(trace + *tracepos));
-               *tracepos += sizeof(uint32_t);
-               uint16_t next_duration = *((uint16_t *)(trace + *tracepos));
-               *tracepos += sizeof(uint16_t);
-               uint16_t next_data_len = *((uint16_t *)(trace + *tracepos)) & 0x7FFF;
-               *tracepos += sizeof(uint16_t);
-               uint8_t *next_frame = (trace + *tracepos);
-               *tracepos += next_data_len;
-               if ((next_data_len == 1) && (*data_len + next_data_len <= MAX_TOPAZ_READER_CMD_LEN)) {
-                       memcpy(topaz_reader_command + *data_len, next_frame, next_data_len);
-                       *data_len += next_data_len;
-                       last_timestamp = next_timestamp + next_duration;
-               } else {
-                       // rewind and exit
-                       *tracepos = *tracepos - next_data_len - sizeof(uint16_t) - sizeof(uint16_t) - sizeof(uint32_t);
-                       break;
-               }
-               uint16_t next_parity_len = (next_data_len-1)/8 + 1;
-               *tracepos += next_parity_len;
-       }
-
-       *duration = last_timestamp - timestamp;
-
-       return true;
-}
-
-
-uint16_t printTraceLine(uint16_t tracepos, uint16_t traceLen, uint8_t *trace, uint8_t protocol, bool showWaitCycles, bool markCRCBytes)
-{
-       bool isResponse;
-       uint16_t data_len, parity_len;
-       uint32_t duration;
-       uint8_t topaz_reader_command[9];
-       uint32_t timestamp, first_timestamp, EndOfTransmissionTimestamp;
-       char explanation[30] = {0};
-       uint8_t mfData[32] = {0};
-       size_t mfDataLen = 0;
-
-       if (tracepos + sizeof(uint32_t) + sizeof(uint16_t) + sizeof(uint16_t) > traceLen) return traceLen;
-
-       first_timestamp = *((uint32_t *)(trace));
-       timestamp = *((uint32_t *)(trace + tracepos));
-
-       tracepos += 4;
-       duration = *((uint16_t *)(trace + tracepos));
-       tracepos += 2;
-       data_len = *((uint16_t *)(trace + tracepos));
-       tracepos += 2;
-
-       if (data_len & 0x8000) {
-         data_len &= 0x7fff;
-         isResponse = true;
-       } else {
-         isResponse = false;
-       }
-       parity_len = (data_len-1)/8 + 1;
-
-       if (tracepos + data_len + parity_len > traceLen) {
-               return traceLen;
-       }
-       uint8_t *frame = trace + tracepos;
-       tracepos += data_len;
-       uint8_t *parityBytes = trace + tracepos;
-       tracepos += parity_len;
-
-       if (protocol == TOPAZ && !isResponse) {
-               // topaz reader commands come in 1 or 9 separate frames with 7 or 8 Bits each.
-               // merge them:
-               if (merge_topaz_reader_frames(timestamp, &duration, &tracepos, traceLen, trace, frame, topaz_reader_command, &data_len)) {
-                       frame = topaz_reader_command;
-               }
-       }
-
-       //Check the CRC status
-       uint8_t crcStatus = 2;
-
-       if (data_len > 2) {
-               switch (protocol) {
-                       case ICLASS:
-                               crcStatus = iclass_CRC_check(isResponse, frame, data_len);
-                               break;
-                       case ISO_14443B:
-                       case TOPAZ:
-                               crcStatus = iso14443B_CRC_check(isResponse, frame, data_len);
-                               break;
-                       case PROTO_MIFARE:
-                               crcStatus = mifare_CRC_check(isResponse, frame, data_len);
-                               break;
-                       case ISO_14443A:
-                               crcStatus = iso14443A_CRC_check(isResponse, frame, data_len);
-                               break;
-                       default:
-                               break;
-               }
-       }
-       //0 CRC-command, CRC not ok
-       //1 CRC-command, CRC ok
-       //2 Not crc-command
-
-       //--- Draw the data column
-       //char line[16][110];
-       char line[16][110];
-
-       for (int j = 0; j < data_len && j/16 < 16; j++) {
-
-               uint8_t parityBits = parityBytes[j>>3];
-               if (protocol != ISO_14443B && (isResponse || protocol == ISO_14443A) && (oddparity8(frame[j]) != ((parityBits >> (7-(j&0x0007))) & 0x01))) {
-                       snprintf(line[j/16]+(( j % 16) * 4), 110, " %02x!", frame[j]);
-               } else {
-                       snprintf(line[j/16]+(( j % 16) * 4), 110, " %02x ", frame[j]);
-               }
-
-       }
-
-       if (markCRCBytes) {
-               if(crcStatus == 0 || crcStatus == 1)
-               {//CRC-command
-                       char *pos1 = line[(data_len-2)/16]+(((data_len-2) % 16) * 4);
-                       (*pos1) = '[';
-                       char *pos2 = line[(data_len)/16]+(((data_len) % 16) * 4);
-                       sprintf(pos2, "%c", ']');
-               }
-       }
-
-       if (data_len == 0) {
-               sprintf(line[0]," <empty trace - possible error>");
-       }
-
-       //--- Draw the CRC column
-       char *crc = (crcStatus == 0 ? "!crc" : (crcStatus == 1 ? " ok " : "    "));
-
-       EndOfTransmissionTimestamp = timestamp + duration;
-
-       if (protocol == PROTO_MIFARE)
-               annotateMifare(explanation, sizeof(explanation), frame, data_len, parityBytes, parity_len, isResponse);
-
-       if(!isResponse)
-       {
-               switch(protocol) {
-                       case ICLASS:            annotateIclass(explanation,sizeof(explanation),frame,data_len); break;
-                       case ISO_14443A:        annotateIso14443a(explanation,sizeof(explanation),frame,data_len); break;
-                       case ISO_14443B:        annotateIso14443b(explanation,sizeof(explanation),frame,data_len); break;
-                       case TOPAZ:                     annotateTopaz(explanation,sizeof(explanation),frame,data_len); break;
-                       default:                        break;
-               }
-       }
-
-       int num_lines = MIN((data_len - 1)/16 + 1, 16);
-       for (int j = 0; j < num_lines ; j++) {
-               if (j == 0) {
-                       PrintAndLog(" %10d | %10d | %s |%-64s | %s| %s",
-                               (timestamp - first_timestamp),
-                               (EndOfTransmissionTimestamp - first_timestamp),
-                               (isResponse ? "Tag" : "Rdr"),
-                               line[j],
-                               (j == num_lines-1) ? crc : "    ",
-                               (j == num_lines-1) ? explanation : "");
-               } else {
-                       PrintAndLog("            |            |     |%-64s | %s| %s",
-                               line[j],
-                               (j == num_lines-1) ? crc : "    ",
-                               (j == num_lines-1) ? explanation : "");
-               }
-       }
-
-       if (DecodeMifareData(frame, data_len, parityBytes, isResponse, mfData, &mfDataLen)) {
-               memset(explanation, 0x00, sizeof(explanation));
-               if (!isResponse) {
-                       explanation[0] = '>';
-                       annotateIso14443a(&explanation[1], sizeof(explanation) - 1, mfData, mfDataLen);
-               }
-               uint8_t crcc = iso14443A_CRC_check(isResponse, mfData, mfDataLen);
-               PrintAndLog("            |          * | dec |%-64s | %-4s| %s",
-                       sprint_hex(mfData, mfDataLen),
-                       (crcc == 0 ? "!crc" : (crcc == 1 ? " ok " : "    ")),
-                       (true) ? explanation : "");
-       };
-
-       if (is_last_record(tracepos, trace, traceLen)) return traceLen;
-
-       if (showWaitCycles && !isResponse && next_record_is_response(tracepos, trace)) {
-               uint32_t next_timestamp = *((uint32_t *)(trace + tracepos));
-               PrintAndLog(" %10d | %10d | %s | fdt (Frame Delay Time): %d",
-                       (EndOfTransmissionTimestamp - first_timestamp),
-                       (next_timestamp - first_timestamp),
-                       "   ",
-                       (next_timestamp - EndOfTransmissionTimestamp));
-       }
-
-       return tracepos;
-}
-
-
-int CmdHFList(const char *Cmd)
-{
-       #ifdef WITH_SMARTCARD
-               PrintAndLog("TEST_WITH_SMARTCARD");
-       #endif
-       #ifdef WITH_TEST
-               PrintAndLog("TEST_WITH_TEST");
-       #endif
-       bool showWaitCycles = false;
-       bool markCRCBytes = false;
-       bool loadFromFile = false;
-       bool saveToFile = false;
-       char param1 = '\0';
-       char param2 = '\0';
-       char param3 = '\0';
-       char type[40] = {0};
-       char filename[FILE_PATH_SIZE] = {0};
-       uint8_t protocol = 0;
-
-       // parse command line
-       int tlen = param_getstr(Cmd, 0, type, sizeof(type));
-       if (param_getlength(Cmd, 1) == 1) {
-               param1 = param_getchar(Cmd, 1);
-       } else {
-               param_getstr(Cmd, 1, filename, sizeof(filename));
-       }
-       if (param_getlength(Cmd, 2) == 1) {
-               param2 = param_getchar(Cmd, 2);
-       } else if (strlen(filename) == 0) {
-               param_getstr(Cmd, 2, filename, sizeof(filename));
-       }
-       if (param_getlength(Cmd, 3) == 1) {
-               param3 = param_getchar(Cmd, 3);
-       } else if (strlen(filename) == 0) {
-               param_getstr(Cmd, 3, filename, sizeof(filename));
-       }
-
-       // Validate param1
-       bool errors = false;
-
-       if(tlen == 0) {
-               errors = true;
-       }
-
-       if(param1 == 'h'
-                       || (param1 != 0 && param1 != 'f' && param1 != 'c' && param1 != 'l')
-                       || (param2 != 0 && param2 != 'f' && param2 != 'c' && param2 != 'l')
-                       || (param3 != 0 && param3 != 'f' && param3 != 'c' && param3 != 'l')) {
-               errors = true;
-       }
-
-       if(!errors) {
-               if(strcmp(type, "iclass") == 0) {
-                       protocol = ICLASS;
-               } else if(strcmp(type, "mf") == 0) {
-                       protocol = PROTO_MIFARE;
-               } else if(strcmp(type, "14a") == 0) {
-                       protocol = ISO_14443A;
-               } else if(strcmp(type, "14b") == 0)     {
-                       protocol = ISO_14443B;
-               } else if(strcmp(type,"topaz") == 0) {
-                       protocol = TOPAZ;
-               } else if(strcmp(type, "7816") == 0) {
-                       protocol = ISO_7816_4;
-               } else if(strcmp(type,"raw") == 0) {
-                       protocol = -1; //No crc, no annotations
-               } else if (strcmp(type, "save") == 0) {
-                       saveToFile = true;
-               } else {
-                       errors = true;
-               }
-       }
-
-       if (param1 == 'f' || param2 == 'f' || param3 == 'f') {
-               showWaitCycles = true;
-       }
-
-       if (param1 == 'c' || param2 == 'c' || param3 == 'c') {
-               markCRCBytes = true;
-       }
-
-       if (param1 == 'l' || param2 == 'l' || param3 == 'l') {
-               loadFromFile = true;
-       }
-
-       if ((loadFromFile || saveToFile) && strlen(filename) == 0) {
-               errors = true;
-       }
-
-       if (loadFromFile && saveToFile) {
-               errors = true;
-       }
-
-       if (errors) {
-               PrintAndLog("List or save protocol data.");
-               PrintAndLog("Usage:  hf list <protocol> [f] [c] [l <filename>]");
-               PrintAndLog("        hf list save <filename>");
-               PrintAndLog("    f      - show frame delay times as well");
-               PrintAndLog("    c      - mark CRC bytes");
-               PrintAndLog("    l      - load data from file instead of trace buffer");
-               PrintAndLog("    save   - save data to file");
-               PrintAndLog("Supported <protocol> values:");
-               PrintAndLog("    raw    - just show raw data without annotations");
-               PrintAndLog("    14a    - interpret data as iso14443a communications");
-               PrintAndLog("    mf     - interpret data as iso14443a communications and decrypt crypto1 stream");
-               PrintAndLog("    14b    - interpret data as iso14443b communications");
-               PrintAndLog("    iclass - interpret data as iclass communications");
-               PrintAndLog("    topaz  - interpret data as topaz communications");
-               PrintAndLog("");
-               PrintAndLog("example: hf list 14a f");
-               PrintAndLog("example: hf list iclass");
-               PrintAndLog("example: hf list save myCardTrace.trc");
-               PrintAndLog("example: hf list 14a l myCardTrace.trc");
-               return 0;
-       }
-
-
-       uint8_t *trace;
-       uint32_t tracepos = 0;
-       uint32_t traceLen = 0;
-
-       if (loadFromFile) {
-               #define TRACE_CHUNK_SIZE (1<<16)                // 64K to start with. Will be enough for BigBuf and some room for future extensions
-               FILE *tracefile = NULL;
-               size_t bytes_read;
-               trace = malloc(TRACE_CHUNK_SIZE);
-               if (trace == NULL) {
-                       PrintAndLog("Cannot allocate memory for trace");
-                       return 2;
-               }
-               if ((tracefile = fopen(filename,"rb")) == NULL) {
-                       PrintAndLog("Could not open file %s", filename);
-                       free(trace);
-                       return 0;
-               }
-               while (!feof(tracefile)) {
-                       bytes_read = fread(trace+traceLen, 1, TRACE_CHUNK_SIZE, tracefile);
-                       traceLen += bytes_read;
-                       if (!feof(tracefile)) {
-                               uint8_t *p = realloc(trace, traceLen + TRACE_CHUNK_SIZE);
-                               if (p == NULL) {
-                                       PrintAndLog("Cannot allocate memory for trace");
-                                       free(trace);
-                                       fclose(tracefile);
-                                       return 2;
-                               }
-                               trace = p;
-                       }
-               }
-               fclose(tracefile);
-       } else {
-               trace = malloc(USB_CMD_DATA_SIZE);
-               // Query for the size of the trace
-               UsbCommand response;
-               GetFromBigBuf(trace, USB_CMD_DATA_SIZE, 0, &response, -1, false);
-               traceLen = response.arg[2];
-               if (traceLen > USB_CMD_DATA_SIZE) {
-                       uint8_t *p = realloc(trace, traceLen);
-                       if (p == NULL) {
-                               PrintAndLog("Cannot allocate memory for trace");
-                               free(trace);
-                               return 2;
-                       }
-                       trace = p;
-                       GetFromBigBuf(trace, traceLen, 0, NULL, -1, false);
-               }
-       }
-
-       if (saveToFile) {
-               FILE *tracefile = NULL;
-               if ((tracefile = fopen(filename,"wb")) == NULL) {
-                       PrintAndLog("Could not create file %s", filename);
-                       return 1;
-               }
-               fwrite(trace, 1, traceLen, tracefile);
-               PrintAndLog("Recorded Activity (TraceLen = %d bytes) written to file %s", traceLen, filename);
-               fclose(tracefile);
-       } else {
-               PrintAndLog("Recorded Activity (TraceLen = %d bytes)", traceLen);
-               PrintAndLog("");
-               PrintAndLog("Start = Start of Start Bit, End = End of last modulation. Src = Source of Transfer");
-               PrintAndLog("iso14443a - All times are in carrier periods (1/13.56Mhz)");
-               PrintAndLog("iClass    - Timings are not as accurate");
-               PrintAndLog("");
-               PrintAndLog("      Start |        End | Src | Data (! denotes parity error)                                   | CRC | Annotation         |");
-               PrintAndLog("------------|------------|-----|-----------------------------------------------------------------|-----|--------------------|");
-
-               ClearAuthData();
-               while(tracepos < traceLen)
-               {
-                       tracepos = printTraceLine(tracepos, traceLen, trace, protocol, showWaitCycles, markCRCBytes);
-               }
-       }
-
-       free(trace);
-       return 0;
-}
-
 int CmdHFSearch(const char *Cmd){
        int ans = 0;
        PrintAndLog("");
index 026357b5a973b4c133cc2e14fa5d4b8d08737584..ff20a950a1dc63cb3ef5fd87fb13ffe9b5711c0a 100644 (file)
@@ -13,5 +13,5 @@

 int CmdHF(const char *Cmd);
 int CmdHFTune(const char *Cmd);
-int CmdHFList(const char *Cmd);
+
 #endif
index 5538b6fb8a50ff71b2b9d2127cf72824c33ceaca..67326c9883379d9b9dfc2695b1833283e6ac56f6 100644 (file)
@@ -1,11 +1,12 @@
 //-----------------------------------------------------------------------------
+// Copyright (C) 2010 iZsh <izsh at fail0verflow.com>
 // Copyright (C) Merlok - 2017
 //
 // This code is licensed to you under the terms of the GNU GPL, version 2 or,
 // at your option, any later version. See the LICENSE.txt file for the text of
 // the license.
 //-----------------------------------------------------------------------------
-// Command: hf mf list. It shows data from arm buffer.
+// Command: hf list. It shows data from arm buffer.
 //-----------------------------------------------------------------------------

 #include "cmdhflist.h"
 #include <stdbool.h>
 #include "util.h"
 #include "ui.h"
+#include "comms.h"
 #include "iso14443crc.h"
+#include "iso15693tools.h"
 #include "parity.h"
 #include "protocols.h"
 #include "crapto1/crapto1.h"
 #include "mifarehost.h"
 #include "mifaredefault.h"
+#include "usb_cmd.h"

+typedef struct {
+       uint32_t uid;       // UID
+       uint32_t nt;        // tag challenge
+       uint32_t nt_enc;    // encrypted tag challenge
+       uint8_t nt_enc_par; // encrypted tag challenge parity
+       uint32_t nr_enc;    // encrypted reader challenge
+       uint32_t ar_enc;    // encrypted reader response
+       uint8_t ar_enc_par; // encrypted reader response parity
+       uint32_t at_enc;    // encrypted tag response
+       uint8_t at_enc_par; // encrypted tag response parity
+       bool first_auth;    // is first authentication
+       uint32_t ks2;           // ar ^ ar_enc
+       uint32_t ks3;       // at ^ at_enc
+} TAuthData;

 enum MifareAuthSeq {
        masNone,
@@ -35,10 +53,11 @@ enum MifareAuthSeq {
        masData,
        masError,
 };
+
 static enum MifareAuthSeq MifareAuthState;
 static TAuthData AuthData;

-void ClearAuthData() {
+static void ClearAuthData() {
        AuthData.uid = 0;
        AuthData.nt = 0;
        AuthData.first_auth = true;
@@ -55,7 +74,7 @@ void ClearAuthData() {
  *          1 : CRC-command, CRC ok
  *          2 : Not crc-command
  */
-uint8_t iso14443A_CRC_check(bool isResponse, uint8_t* data, uint8_t len)
+static uint8_t iso14443A_CRC_check(bool isResponse, uint8_t* data, uint8_t len)
 {
        uint8_t b1,b2;

@@ -71,7 +90,8 @@ uint8_t iso14443A_CRC_check(bool isResponse, uint8_t* data, uint8_t len)
        }
 }

-uint8_t mifare_CRC_check(bool isResponse, uint8_t* data, uint8_t len)
+
+static uint8_t mifare_CRC_check(bool isResponse, uint8_t* data, uint8_t len)
 {
        switch(MifareAuthState) {
                case masNone:
@@ -82,6 +102,101 @@ uint8_t mifare_CRC_check(bool isResponse, uint8_t* data, uint8_t len)
        }
 }

+
+/**
+ * @brief iso14443B_CRC_check Checks CRC in command or response
+ * @param isResponse
+ * @param data
+ * @param len
+ * @return  0 : CRC-command, CRC not ok
+ *          1 : CRC-command, CRC ok
+ *          2 : Not crc-command
+ */
+static uint8_t iso14443B_CRC_check(bool isResponse, uint8_t* data, uint8_t len)
+{
+       uint8_t b1,b2;
+
+       if(len <= 2) return 2;
+
+       ComputeCrc14443(CRC_14443_B, data, len-2, &b1, &b2);
+       if(b1 != data[len-2] || b2 != data[len-1]) {
+               return 0;
+       } else {
+               return 1;
+       }
+}
+
+
+static uint8_t iso15693_CRC_check(uint8_t* d, uint16_t n)
+{
+       if (n <= 2) return 2;
+
+       return (Iso15693Crc(d, n) == ISO15693_CRC_CHECK ? 1 : 0);
+}
+
+
+/**
+ * @brief iclass_CRC_Ok Checks CRC in command or response
+ * @param isResponse
+ * @param data
+ * @param len
+ * @return  0 : CRC-command, CRC not ok
+ *             1 : CRC-command, CRC ok
+ *          2 : Not crc-command
+ */
+uint8_t iclass_CRC_check(bool isResponse, uint8_t* data, uint8_t len)
+{
+       if(len < 4) return 2;//CRC commands (and responses) are all at least 4 bytes
+
+       uint8_t b1, b2;
+
+       if(!isResponse)//Commands to tag
+       {
+               /**
+                 These commands should have CRC. Total length leftmost
+                 4     READ
+                 4 READ4
+                 12 UPDATE - unsecured, ends with CRC16
+                 14 UPDATE - secured, ends with signature instead
+                 4 PAGESEL
+                 **/
+               if(len == 4 || len == 12)//Covers three of them
+               {
+                       //Don't include the command byte
+                       ComputeCrc14443(CRC_ICLASS, (data+1), len-3, &b1, &b2);
+                       return b1 == data[len -2] && b2 == data[len-1];
+               }
+               return 2;
+       }else{
+               /**
+               These tag responses should have CRC. Total length leftmost
+
+               10  READ                data[8] crc[2]
+               34  READ4               data[32]crc[2]
+               10  UPDATE      data[8] crc[2]
+               10 SELECT       csn[8] crc[2]
+               10  IDENTIFY  asnb[8] crc[2]
+               10  PAGESEL   block1[8] crc[2]
+               10  DETECT    csn[8] crc[2]
+
+               These should not
+
+               4  CHECK                chip_response[4]
+               8  READCHECK data[8]
+               1  ACTALL    sof[1]
+               1  ACT       sof[1]
+
+               In conclusion, without looking at the command; any response
+               of length 10 or 34 should have CRC
+                 **/
+               if(len != 10 && len != 34) return true;
+
+               ComputeCrc14443(CRC_ICLASS, data, len-2, &b1, &b2);
+               return b1 == data[len -2] && b2 == data[len-1];
+       }
+}
+
+
 void annotateIclass(char *exp, size_t size, uint8_t* cmd, uint8_t cmdsize)
 {
        switch(cmd[0])
@@ -110,36 +225,33 @@ void annotateIclass(char *exp, size_t size, uint8_t* cmd, uint8_t cmdsize)
        return;
 }

+
 void annotateIso15693(char *exp, size_t size, uint8_t* cmd, uint8_t cmdsize)
 {
-
-       if(cmd[0] == 0x26)
-       {
-               switch(cmd[1]){
-               case ISO15693_INVENTORY           :snprintf(exp, size, "INVENTORY");break;
-               case ISO15693_STAYQUIET           :snprintf(exp, size, "STAY_QUIET");break;
-               default:                     snprintf(exp,size,"?"); break;
-
-               }
-       }else if(cmd[0] == 0x02)
-       {
-               switch(cmd[1])
-               {
-               case ISO15693_READBLOCK            :snprintf(exp, size, "READBLOCK");break;
-               case ISO15693_WRITEBLOCK           :snprintf(exp, size, "WRITEBLOCK");break;
-               case ISO15693_LOCKBLOCK            :snprintf(exp, size, "LOCKBLOCK");break;
-               case ISO15693_READ_MULTI_BLOCK     :snprintf(exp, size, "READ_MULTI_BLOCK");break;
-               case ISO15693_SELECT               :snprintf(exp, size, "SELECT");break;
-               case ISO15693_RESET_TO_READY       :snprintf(exp, size, "RESET_TO_READY");break;
-               case ISO15693_WRITE_AFI            :snprintf(exp, size, "WRITE_AFI");break;
-               case ISO15693_LOCK_AFI             :snprintf(exp, size, "LOCK_AFI");break;
-               case ISO15693_WRITE_DSFID          :snprintf(exp, size, "WRITE_DSFID");break;
-               case ISO15693_LOCK_DSFID           :snprintf(exp, size, "LOCK_DSFID");break;
-               case ISO15693_GET_SYSTEM_INFO      :snprintf(exp, size, "GET_SYSTEM_INFO");break;
-               case ISO15693_READ_MULTI_SECSTATUS :snprintf(exp, size, "READ_MULTI_SECSTATUS");break;
-               default:                            snprintf(exp,size,"?"); break;
-               }
+       switch(cmd[1]){
+               // Mandatory Commands, all Tags must support them:
+               case ISO15693_INVENTORY                         :snprintf(exp, size, "INVENTORY");return;
+               case ISO15693_STAYQUIET                         :snprintf(exp, size, "STAY_QUIET");return;
+               // Optional Commands, Tags may support them:
+               case ISO15693_READBLOCK                         :snprintf(exp, size, "READBLOCK");return;
+               case ISO15693_WRITEBLOCK                        :snprintf(exp, size, "WRITEBLOCK");return;
+               case ISO15693_LOCKBLOCK                         :snprintf(exp, size, "LOCKBLOCK");return;
+               case ISO15693_READ_MULTI_BLOCK          :snprintf(exp, size, "READ_MULTI_BLOCK");return;
+               case ISO15693_SELECT                            :snprintf(exp, size, "SELECT");return;
+               case ISO15693_RESET_TO_READY            :snprintf(exp, size, "RESET_TO_READY");return;
+               case ISO15693_WRITE_AFI                         :snprintf(exp, size, "WRITE_AFI");return;
+               case ISO15693_LOCK_AFI                          :snprintf(exp, size, "LOCK_AFI");return;
+               case ISO15693_WRITE_DSFID                       :snprintf(exp, size, "WRITE_DSFID");return;
+               case ISO15693_LOCK_DSFID                        :snprintf(exp, size, "LOCK_DSFID");return;
+               case ISO15693_GET_SYSTEM_INFO           :snprintf(exp, size, "GET_SYSTEM_INFO");return;
+               case ISO15693_READ_MULTI_SECSTATUS      :snprintf(exp, size, "READ_MULTI_SECSTATUS");return;
+               default: break;
        }
+
+       if (cmd[1] > ISO15693_STAYQUIET && cmd[1] < ISO15693_READBLOCK) snprintf(exp, size, "Mandatory RFU");
+       else if (cmd[1] > ISO15693_READ_MULTI_SECSTATUS && cmd[1] <= 0x9F) snprintf(exp, size, "Optional RFU");
+       else if ( cmd[1] >= 0xA0 && cmd[1] <= 0xDF ) snprintf(exp, size, "Custom command");
+       else if ( cmd[1] >= 0xE0 && cmd[1] <= 0xFF ) snprintf(exp, size, "Proprietary command");
 }


@@ -367,7 +479,103 @@ void annotateMifare(char *exp, size_t size, uint8_t* cmd, uint8_t cmdsize, uint8

 }

-bool DecodeMifareData(uint8_t *cmd, uint8_t cmdsize, uint8_t *parity, bool isResponse, uint8_t *mfData, size_t *mfDataLen) {
+
+static uint64_t GetCrypto1ProbableKey(TAuthData *ad) {
+       struct Crypto1State *revstate = lfsr_recovery64(ad->ks2, ad->ks3);
+       lfsr_rollback_word(revstate, 0, 0);
+       lfsr_rollback_word(revstate, 0, 0);
+       lfsr_rollback_word(revstate, ad->nr_enc, 1);
+       lfsr_rollback_word(revstate, ad->uid ^ ad->nt, 0);
+
+       uint64_t lfsr = 0;
+       crypto1_get_lfsr(revstate, &lfsr);
+       crypto1_destroy(revstate);
+
+       return lfsr;
+}
+
+
+static bool NTParityChk(TAuthData *ad, uint32_t ntx) {
+       if (
+               (oddparity8(ntx >> 8 & 0xff) ^ (ntx & 0x01) ^ ((ad->nt_enc_par >> 5) & 0x01) ^ (ad->nt_enc & 0x01)) ||
+               (oddparity8(ntx >> 16 & 0xff) ^ (ntx >> 8 & 0x01) ^ ((ad->nt_enc_par >> 6) & 0x01) ^ (ad->nt_enc >> 8 & 0x01)) ||
+               (oddparity8(ntx >> 24 & 0xff) ^ (ntx >> 16 & 0x01) ^ ((ad->nt_enc_par >> 7) & 0x01) ^ (ad->nt_enc >> 16 & 0x01))
+               )
+               return false;
+
+       uint32_t ar = prng_successor(ntx, 64);
+       if (
+               (oddparity8(ar >> 8 & 0xff) ^ (ar & 0x01) ^ ((ad->ar_enc_par >> 5) & 0x01) ^ (ad->ar_enc & 0x01)) ||
+               (oddparity8(ar >> 16 & 0xff) ^ (ar >> 8 & 0x01) ^ ((ad->ar_enc_par >> 6) & 0x01) ^ (ad->ar_enc >> 8 & 0x01)) ||
+               (oddparity8(ar >> 24 & 0xff) ^ (ar >> 16 & 0x01) ^ ((ad->ar_enc_par >> 7) & 0x01) ^ (ad->ar_enc >> 16 & 0x01))
+               )
+               return false;
+
+       uint32_t at = prng_successor(ntx, 96);
+       if (
+               (oddparity8(ar & 0xff) ^ (at >> 24 & 0x01) ^ ((ad->ar_enc_par >> 4) & 0x01) ^ (ad->at_enc >> 24 & 0x01)) ||
+               (oddparity8(at >> 8 & 0xff) ^ (at & 0x01) ^ ((ad->at_enc_par >> 5) & 0x01) ^ (ad->at_enc & 0x01)) ||
+               (oddparity8(at >> 16 & 0xff) ^ (at >> 8 & 0x01) ^ ((ad->at_enc_par >> 6) & 0x01) ^ (ad->at_enc >> 8 & 0x01)) ||
+               (oddparity8(at >> 24 & 0xff) ^ (at >> 16 & 0x01) ^ ((ad->at_enc_par >> 7) & 0x01) ^ (ad->at_enc >> 16 & 0x01))
+               )
+               return false;
+
+       return true;
+}
+
+
+static bool CheckCrypto1Parity(uint8_t *cmd_enc, uint8_t cmdsize, uint8_t *cmd, uint8_t *parity_enc) {
+       for (int i = 0; i < cmdsize - 1; i++) {
+               if (oddparity8(cmd[i]) ^ (cmd[i + 1] & 0x01) ^ ((parity_enc[i / 8] >> (7 - i % 8)) & 0x01) ^ (cmd_enc[i + 1] & 0x01))
+                       return false;
+       }
+
+       return true;
+}
+
+
+static bool NestedCheckKey(uint64_t key, TAuthData *ad, uint8_t *cmd, uint8_t cmdsize, uint8_t *parity) {
+       uint8_t buf[32] = {0};
+       struct Crypto1State *pcs;
+
+       AuthData.ks2 = 0;
+       AuthData.ks3 = 0;
+
+       pcs = crypto1_create(key);
+       uint32_t nt1 = crypto1_word(pcs, ad->nt_enc ^ ad->uid, 1) ^ ad->nt_enc;
+       uint32_t ar = prng_successor(nt1, 64);
+       uint32_t at = prng_successor(nt1, 96);
+
+       crypto1_word(pcs, ad->nr_enc, 1);
+//     uint32_t nr1 = crypto1_word(pcs, ad->nr_enc, 1) ^ ad->nr_enc;  // if needs deciphered nr
+       uint32_t ar1 = crypto1_word(pcs, 0, 0) ^ ad->ar_enc;
+       uint32_t at1 = crypto1_word(pcs, 0, 0) ^ ad->at_enc;
+
+       if (!(ar == ar1 && at == at1 && NTParityChk(ad, nt1))) {
+               crypto1_destroy(pcs);
+               return false;
+       }
+
+       memcpy(buf, cmd, cmdsize);
+       mf_crypto1_decrypt(pcs, buf, cmdsize, 0);
+
+       crypto1_destroy(pcs);
+
+       if (!CheckCrypto1Parity(cmd, cmdsize, buf, parity))
+               return false;
+
+       if(!CheckCrc14443(CRC_14443_A, buf, cmdsize))
+               return false;
+
+       AuthData.nt = nt1;
+       AuthData.ks2 = AuthData.ar_enc ^ ar;
+       AuthData.ks3 = AuthData.at_enc ^ at;
+
+       return true;
+}
+
+
+static bool DecodeMifareData(uint8_t *cmd, uint8_t cmdsize, uint8_t *parity, bool isResponse, uint8_t *mfData, size_t *mfDataLen) {
        static struct Crypto1State *traceCrypto1;
        static uint64_t mfLastKey;

@@ -514,93 +722,415 @@ bool DecodeMifareData(uint8_t *cmd, uint8_t cmdsize, uint8_t *parity, bool isRes
        return *mfDataLen > 0;
 }

-bool NTParityChk(TAuthData *ad, uint32_t ntx) {
-       if (
-               (oddparity8(ntx >> 8 & 0xff) ^ (ntx & 0x01) ^ ((ad->nt_enc_par >> 5) & 0x01) ^ (ad->nt_enc & 0x01)) ||
-               (oddparity8(ntx >> 16 & 0xff) ^ (ntx >> 8 & 0x01) ^ ((ad->nt_enc_par >> 6) & 0x01) ^ (ad->nt_enc >> 8 & 0x01)) ||
-               (oddparity8(ntx >> 24 & 0xff) ^ (ntx >> 16 & 0x01) ^ ((ad->nt_enc_par >> 7) & 0x01) ^ (ad->nt_enc >> 16 & 0x01))
-               )
-               return false;
+
+bool is_last_record(uint16_t tracepos, uint8_t *trace, uint16_t traceLen)
+{
+       return(tracepos + sizeof(uint32_t) + sizeof(uint16_t) + sizeof(uint16_t) >= traceLen);
+}
+
+
+bool next_record_is_response(uint16_t tracepos, uint8_t *trace)
+{
+       uint16_t next_records_datalen = *((uint16_t *)(trace + tracepos + sizeof(uint32_t) + sizeof(uint16_t)));

-       uint32_t ar = prng_successor(ntx, 64);
-       if (
-               (oddparity8(ar >> 8 & 0xff) ^ (ar & 0x01) ^ ((ad->ar_enc_par >> 5) & 0x01) ^ (ad->ar_enc & 0x01)) ||
-               (oddparity8(ar >> 16 & 0xff) ^ (ar >> 8 & 0x01) ^ ((ad->ar_enc_par >> 6) & 0x01) ^ (ad->ar_enc >> 8 & 0x01)) ||
-               (oddparity8(ar >> 24 & 0xff) ^ (ar >> 16 & 0x01) ^ ((ad->ar_enc_par >> 7) & 0x01) ^ (ad->ar_enc >> 16 & 0x01))
-               )
-               return false;
+       return(next_records_datalen & 0x8000);
+}

-       uint32_t at = prng_successor(ntx, 96);
-       if (
-               (oddparity8(ar & 0xff) ^ (at >> 24 & 0x01) ^ ((ad->ar_enc_par >> 4) & 0x01) ^ (ad->at_enc >> 24 & 0x01)) ||
-               (oddparity8(at >> 8 & 0xff) ^ (at & 0x01) ^ ((ad->at_enc_par >> 5) & 0x01) ^ (ad->at_enc & 0x01)) ||
-               (oddparity8(at >> 16 & 0xff) ^ (at >> 8 & 0x01) ^ ((ad->at_enc_par >> 6) & 0x01) ^ (ad->at_enc >> 8 & 0x01)) ||
-               (oddparity8(at >> 24 & 0xff) ^ (at >> 16 & 0x01) ^ ((ad->at_enc_par >> 7) & 0x01) ^ (ad->at_enc >> 16 & 0x01))
-               )
-               return false;
-
+
+bool merge_topaz_reader_frames(uint32_t timestamp, uint32_t *duration, uint16_t *tracepos, uint16_t traceLen, uint8_t *trace, uint8_t *frame, uint8_t *topaz_reader_command, uint16_t *data_len)
+{
+
+#define MAX_TOPAZ_READER_CMD_LEN       16
+
+       uint32_t last_timestamp = timestamp + *duration;
+
+       if ((*data_len != 1) || (frame[0] == TOPAZ_WUPA) || (frame[0] == TOPAZ_REQA)) return false;
+
+       memcpy(topaz_reader_command, frame, *data_len);
+
+       while (!is_last_record(*tracepos, trace, traceLen) && !next_record_is_response(*tracepos, trace)) {
+               uint32_t next_timestamp = *((uint32_t *)(trace + *tracepos));
+               *tracepos += sizeof(uint32_t);
+               uint16_t next_duration = *((uint16_t *)(trace + *tracepos));
+               *tracepos += sizeof(uint16_t);
+               uint16_t next_data_len = *((uint16_t *)(trace + *tracepos)) & 0x7FFF;
+               *tracepos += sizeof(uint16_t);
+               uint8_t *next_frame = (trace + *tracepos);
+               *tracepos += next_data_len;
+               if ((next_data_len == 1) && (*data_len + next_data_len <= MAX_TOPAZ_READER_CMD_LEN)) {
+                       memcpy(topaz_reader_command + *data_len, next_frame, next_data_len);
+                       *data_len += next_data_len;
+                       last_timestamp = next_timestamp + next_duration;
+               } else {
+                       // rewind and exit
+                       *tracepos = *tracepos - next_data_len - sizeof(uint16_t) - sizeof(uint16_t) - sizeof(uint32_t);
+                       break;
+               }
+               uint16_t next_parity_len = (next_data_len-1)/8 + 1;
+               *tracepos += next_parity_len;
+       }
+
+       *duration = last_timestamp - timestamp;
+
        return true;
 }

-bool NestedCheckKey(uint64_t key, TAuthData *ad, uint8_t *cmd, uint8_t cmdsize, uint8_t *parity) {
-       uint8_t buf[32] = {0};
-       struct Crypto1State *pcs;
+
+uint16_t printTraceLine(uint16_t tracepos, uint16_t traceLen, uint8_t *trace, uint8_t protocol, bool showWaitCycles, bool markCRCBytes)
+{
+       bool isResponse;
+       uint16_t data_len, parity_len;
+       uint32_t duration;
+       uint8_t topaz_reader_command[9];
+       uint32_t timestamp, first_timestamp, EndOfTransmissionTimestamp;
+       char explanation[30] = {0};
+       uint8_t mfData[32] = {0};
+       size_t mfDataLen = 0;
+
+       if (tracepos + sizeof(uint32_t) + sizeof(uint16_t) + sizeof(uint16_t) > traceLen) return traceLen;

-       AuthData.ks2 = 0;
-       AuthData.ks3 = 0;
+       first_timestamp = *((uint32_t *)(trace));
+       timestamp = *((uint32_t *)(trace + tracepos));

-       pcs = crypto1_create(key);
-       uint32_t nt1 = crypto1_word(pcs, ad->nt_enc ^ ad->uid, 1) ^ ad->nt_enc;
-       uint32_t ar = prng_successor(nt1, 64);
-       uint32_t at = prng_successor(nt1, 96);
+       tracepos += 4;
+       duration = *((uint16_t *)(trace + tracepos));
+       tracepos += 2;
+       data_len = *((uint16_t *)(trace + tracepos));
+       tracepos += 2;

-       crypto1_word(pcs, ad->nr_enc, 1);
-//     uint32_t nr1 = crypto1_word(pcs, ad->nr_enc, 1) ^ ad->nr_enc;  // if needs deciphered nr
-       uint32_t ar1 = crypto1_word(pcs, 0, 0) ^ ad->ar_enc;
-       uint32_t at1 = crypto1_word(pcs, 0, 0) ^ ad->at_enc;
+       if (data_len & 0x8000) {
+         data_len &= 0x7fff;
+         isResponse = true;
+       } else {
+         isResponse = false;
+       }
+       parity_len = (data_len-1)/8 + 1;

-       if (!(ar == ar1 && at == at1 && NTParityChk(ad, nt1))) {
-               crypto1_destroy(pcs);
-               return false;
+       if (tracepos + data_len + parity_len > traceLen) {
+               return traceLen;
        }
+       uint8_t *frame = trace + tracepos;
+       tracepos += data_len;
+       uint8_t *parityBytes = trace + tracepos;
+       tracepos += parity_len;

-       memcpy(buf, cmd, cmdsize);
-       mf_crypto1_decrypt(pcs, buf, cmdsize, 0);
+       if (protocol == TOPAZ && !isResponse) {
+               // topaz reader commands come in 1 or 9 separate frames with 7 or 8 Bits each.
+               // merge them:
+               if (merge_topaz_reader_frames(timestamp, &duration, &tracepos, traceLen, trace, frame, topaz_reader_command, &data_len)) {
+                       frame = topaz_reader_command;
+               }
+       }

-       crypto1_destroy(pcs);
+       //Check the CRC status
+       uint8_t crcStatus = 2;
+
+       if (data_len > 2) {
+               switch (protocol) {
+                       case ICLASS:
+                               crcStatus = iclass_CRC_check(isResponse, frame, data_len);
+                               break;
+                       case ISO_14443B:
+                       case TOPAZ:
+                               crcStatus = iso14443B_CRC_check(isResponse, frame, data_len);
+                               break;
+                       case PROTO_MIFARE:
+                               crcStatus = mifare_CRC_check(isResponse, frame, data_len);
+                               break;
+                       case ISO_14443A:
+                               crcStatus = iso14443A_CRC_check(isResponse, frame, data_len);
+                               break;
+                       case ISO_15693:
+                               crcStatus = iso15693_CRC_check(frame, data_len);
+                               break;
+                       default:
+                               break;
+               }
+       }
+       //0 CRC-command, CRC not ok
+       //1 CRC-command, CRC ok
+       //2 Not crc-command
+
+       //--- Draw the data column
+       //char line[16][110];
+       char line[16][110];
+
+       for (int j = 0; j < data_len && j/16 < 16; j++) {
+
+               uint8_t parityBits = parityBytes[j>>3];
+               if (protocol != ISO_14443B
+                   && protocol != ISO_15693
+                   && protocol != ISO_7816_4
+                   && (isResponse || protocol == ISO_14443A)
+                   && (oddparity8(frame[j]) != ((parityBits >> (7-(j&0x0007))) & 0x01))) {
+                       snprintf(line[j/16]+(( j % 16) * 4), 110, " %02x!", frame[j]);
+               } else {
+                       snprintf(line[j/16]+(( j % 16) * 4), 110, " %02x ", frame[j]);
+               }
+
+       }
+
+       if (markCRCBytes) {
+               if(crcStatus == 0 || crcStatus == 1)
+               {//CRC-command
+                       char *pos1 = line[(data_len-2)/16]+(((data_len-2) % 16) * 4);
+                       (*pos1) = '[';
+                       char *pos2 = line[(data_len)/16]+(((data_len) % 16) * 4);
+                       sprintf(pos2, "%c", ']');
+               }
+       }
+
+       if (data_len == 0) {
+               sprintf(line[0]," <empty trace - possible error>");
+       }
+
+       //--- Draw the CRC column
+       char *crc = (crcStatus == 0 ? "!crc" : (crcStatus == 1 ? " ok " : "    "));
+
+       EndOfTransmissionTimestamp = timestamp + duration;
+
+       if (protocol == PROTO_MIFARE)
+               annotateMifare(explanation, sizeof(explanation), frame, data_len, parityBytes, parity_len, isResponse);

-       if (!CheckCrypto1Parity(cmd, cmdsize, buf, parity))
-               return false;
+       if(!isResponse)
+       {
+               switch(protocol) {
+                       case ICLASS:            annotateIclass(explanation,sizeof(explanation),frame,data_len); break;
+                       case ISO_14443A:        annotateIso14443a(explanation,sizeof(explanation),frame,data_len); break;
+                       case ISO_14443B:        annotateIso14443b(explanation,sizeof(explanation),frame,data_len); break;
+                       case TOPAZ:                     annotateTopaz(explanation,sizeof(explanation),frame,data_len); break;
+                       case ISO_15693:         annotateIso15693(explanation,sizeof(explanation),frame,data_len); break;
+                       default:                        break;
+               }
+       }

-       if(!CheckCrc14443(CRC_14443_A, buf, cmdsize))
-               return false;
+       int num_lines = MIN((data_len - 1)/16 + 1, 16);
+       for (int j = 0; j < num_lines ; j++) {
+               if (j == 0) {
+                       PrintAndLog(" %10d | %10d | %s |%-64s | %s| %s",
+                               (timestamp - first_timestamp),
+                               (EndOfTransmissionTimestamp - first_timestamp),
+                               (isResponse ? "Tag" : "Rdr"),
+                               line[j],
+                               (j == num_lines-1) ? crc : "    ",
+                               (j == num_lines-1) ? explanation : "");
+               } else {
+                       PrintAndLog("            |            |     |%-64s | %s| %s",
+                               line[j],
+                               (j == num_lines-1) ? crc : "    ",
+                               (j == num_lines-1) ? explanation : "");
+               }
+       }

-       AuthData.nt = nt1;
-       AuthData.ks2 = AuthData.ar_enc ^ ar;
-       AuthData.ks3 = AuthData.at_enc ^ at;
+       if (DecodeMifareData(frame, data_len, parityBytes, isResponse, mfData, &mfDataLen)) {
+               memset(explanation, 0x00, sizeof(explanation));
+               if (!isResponse) {
+                       explanation[0] = '>';
+                       annotateIso14443a(&explanation[1], sizeof(explanation) - 1, mfData, mfDataLen);
+               }
+               uint8_t crcc = iso14443A_CRC_check(isResponse, mfData, mfDataLen);
+               PrintAndLog("            |          * | dec |%-64s | %-4s| %s",
+                       sprint_hex(mfData, mfDataLen),
+                       (crcc == 0 ? "!crc" : (crcc == 1 ? " ok " : "    ")),
+                       (true) ? explanation : "");
+       };

-       return true;
+       if (is_last_record(tracepos, trace, traceLen)) return traceLen;
+
+       if (showWaitCycles && !isResponse && next_record_is_response(tracepos, trace)) {
+               uint32_t next_timestamp = *((uint32_t *)(trace + tracepos));
+               PrintAndLog(" %10d | %10d | %s | fdt (Frame Delay Time): %d",
+                       (EndOfTransmissionTimestamp - first_timestamp),
+                       (next_timestamp - first_timestamp),
+                       "   ",
+                       (next_timestamp - EndOfTransmissionTimestamp));
+       }
+
+       return tracepos;
 }

-bool CheckCrypto1Parity(uint8_t *cmd_enc, uint8_t cmdsize, uint8_t *cmd, uint8_t *parity_enc) {
-       for (int i = 0; i < cmdsize - 1; i++) {
-               if (oddparity8(cmd[i]) ^ (cmd[i + 1] & 0x01) ^ ((parity_enc[i / 8] >> (7 - i % 8)) & 0x01) ^ (cmd_enc[i + 1] & 0x01))
-                       return false;
+
+int CmdHFList(const char *Cmd)
+{
+       bool showWaitCycles = false;
+       bool markCRCBytes = false;
+       bool loadFromFile = false;
+       bool saveToFile = false;
+       char param1 = '\0';
+       char param2 = '\0';
+       char param3 = '\0';
+       char type[40] = {0};
+       char filename[FILE_PATH_SIZE] = {0};
+       uint8_t protocol = 0;
+
+       // parse command line
+       int tlen = param_getstr(Cmd, 0, type, sizeof(type));
+       if (param_getlength(Cmd, 1) == 1) {
+               param1 = param_getchar(Cmd, 1);
+       } else {
+               param_getstr(Cmd, 1, filename, sizeof(filename));
+       }
+       if (param_getlength(Cmd, 2) == 1) {
+               param2 = param_getchar(Cmd, 2);
+       } else if (strlen(filename) == 0) {
+               param_getstr(Cmd, 2, filename, sizeof(filename));
+       }
+       if (param_getlength(Cmd, 3) == 1) {
+               param3 = param_getchar(Cmd, 3);
+       } else if (strlen(filename) == 0) {
+               param_getstr(Cmd, 3, filename, sizeof(filename));
+       }
+
+       // Validate param1
+       bool errors = false;
+
+       if(tlen == 0) {
+               errors = true;
+       }
+
+       if(param1 == 'h'
+                       || (param1 != 0 && param1 != 'f' && param1 != 'c' && param1 != 'l')
+                       || (param2 != 0 && param2 != 'f' && param2 != 'c' && param2 != 'l')
+                       || (param3 != 0 && param3 != 'f' && param3 != 'c' && param3 != 'l')) {
+               errors = true;
+       }
+
+       if(!errors) {
+               if (strcmp(type,     "iclass") == 0)    protocol = ICLASS;
+               else if(strcmp(type, "14a") == 0)               protocol = ISO_14443A;
+               else if(strcmp(type, "mf") == 0)                protocol = PROTO_MIFARE;
+               else if(strcmp(type, "14b") == 0)               protocol = ISO_14443B;
+               else if(strcmp(type, "topaz") == 0)             protocol = TOPAZ;
+               else if(strcmp(type, "7816") == 0)              protocol = ISO_7816_4;
+               else if(strcmp(type, "15") == 0)                protocol = ISO_15693;
+               else if(strcmp(type, "raw") == 0)               protocol = -1;//No crc, no annotations
+               else if (strcmp(type, "save") == 0)     saveToFile = true;
+               else errors = true;
        }

-       return true;
-}
+       if (param1 == 'f' || param2 == 'f' || param3 == 'f') {
+               showWaitCycles = true;
+       }

-uint64_t GetCrypto1ProbableKey(TAuthData *ad) {
-       struct Crypto1State *revstate = lfsr_recovery64(ad->ks2, ad->ks3);
-       lfsr_rollback_word(revstate, 0, 0);
-       lfsr_rollback_word(revstate, 0, 0);
-       lfsr_rollback_word(revstate, ad->nr_enc, 1);
-       lfsr_rollback_word(revstate, ad->uid ^ ad->nt, 0);
+       if (param1 == 'c' || param2 == 'c' || param3 == 'c') {
+               markCRCBytes = true;
+       }

-       uint64_t lfsr = 0;
-       crypto1_get_lfsr(revstate, &lfsr);
-       crypto1_destroy(revstate);
+       if (param1 == 'l' || param2 == 'l' || param3 == 'l') {
+               loadFromFile = true;
+       }
+
+       if ((loadFromFile || saveToFile) && strlen(filename) == 0) {
+               errors = true;
+       }
+
+       if (loadFromFile && saveToFile) {
+               errors = true;
+       }

-       return lfsr;
+       if (errors) {
+               PrintAndLog("List or save protocol data.");
+               PrintAndLog("Usage:  hf list <protocol> [f] [c] [l <filename>]");
+               PrintAndLog("        hf list save <filename>");
+               PrintAndLog("    f      - show frame delay times as well");
+               PrintAndLog("    c      - mark CRC bytes");
+               PrintAndLog("    l      - load data from file instead of trace buffer");
+               PrintAndLog("    save   - save data to file");
+               PrintAndLog("Supported <protocol> values:");
+               PrintAndLog("    raw    - just show raw data without annotations");
+               PrintAndLog("    14a    - interpret data as iso14443a communications");
+               PrintAndLog("    mf     - interpret data as iso14443a communications and decrypt crypto1 stream");
+               PrintAndLog("    14b    - interpret data as iso14443b communications");
+               PrintAndLog("    15     - interpret data as iso15693 communications");
+               PrintAndLog("    iclass - interpret data as iclass communications");
+               PrintAndLog("    topaz  - interpret data as topaz communications");
+               PrintAndLog("");
+               PrintAndLog("example: hf list 14a f");
+               PrintAndLog("example: hf list iclass");
+               PrintAndLog("example: hf list save myCardTrace.trc");
+               PrintAndLog("example: hf list 14a l myCardTrace.trc");
+               return 0;
+       }
+
+
+       uint8_t *trace;
+       uint32_t tracepos = 0;
+       uint32_t traceLen = 0;
+
+       if (loadFromFile) {
+               #define TRACE_CHUNK_SIZE (1<<16)                // 64K to start with. Will be enough for BigBuf and some room for future extensions
+               FILE *tracefile = NULL;
+               size_t bytes_read;
+               trace = malloc(TRACE_CHUNK_SIZE);
+               if (trace == NULL) {
+                       PrintAndLog("Cannot allocate memory for trace");
+                       return 2;
+               }
+               if ((tracefile = fopen(filename,"rb")) == NULL) {
+                       PrintAndLog("Could not open file %s", filename);
+                       free(trace);
+                       return 0;
+               }
+               while (!feof(tracefile)) {
+                       bytes_read = fread(trace+traceLen, 1, TRACE_CHUNK_SIZE, tracefile);
+                       traceLen += bytes_read;
+                       if (!feof(tracefile)) {
+                               uint8_t *p = realloc(trace, traceLen + TRACE_CHUNK_SIZE);
+                               if (p == NULL) {
+                                       PrintAndLog("Cannot allocate memory for trace");
+                                       free(trace);
+                                       fclose(tracefile);
+                                       return 2;
+                               }
+                               trace = p;
+                       }
+               }
+               fclose(tracefile);
+       } else {
+               trace = malloc(USB_CMD_DATA_SIZE);
+               // Query for the size of the trace
+               UsbCommand response;
+               GetFromBigBuf(trace, USB_CMD_DATA_SIZE, 0, &response, -1, false);
+               traceLen = response.arg[2];
+               if (traceLen > USB_CMD_DATA_SIZE) {
+                       uint8_t *p = realloc(trace, traceLen);
+                       if (p == NULL) {
+                               PrintAndLog("Cannot allocate memory for trace");
+                               free(trace);
+                               return 2;
+                       }
+                       trace = p;
+                       GetFromBigBuf(trace, traceLen, 0, NULL, -1, false);
+               }
+       }
+
+       if (saveToFile) {
+               FILE *tracefile = NULL;
+               if ((tracefile = fopen(filename,"wb")) == NULL) {
+                       PrintAndLog("Could not create file %s", filename);
+                       return 1;
+               }
+               fwrite(trace, 1, traceLen, tracefile);
+               PrintAndLog("Recorded Activity (TraceLen = %d bytes) written to file %s", traceLen, filename);
+               fclose(tracefile);
+       } else {
+               PrintAndLog("Recorded Activity (TraceLen = %d bytes)", traceLen);
+               PrintAndLog("");
+               PrintAndLog("Start = Start of Start Bit, End = End of last modulation. Src = Source of Transfer");
+               PrintAndLog("iso14443a - All times are in carrier periods (1/13.56Mhz)");
+               PrintAndLog("iClass    - Timings are not as accurate");
+               PrintAndLog("");
+               PrintAndLog("      Start |        End | Src | Data (! denotes parity error)                                   | CRC | Annotation         |");
+               PrintAndLog("------------|------------|-----|-----------------------------------------------------------------|-----|--------------------|");
+
+               ClearAuthData();
+               while(tracepos < traceLen)
+               {
+                       tracepos = printTraceLine(tracepos, traceLen, trace, protocol, showWaitCycles, markCRCBytes);
+               }
+       }
+
+       free(trace);
+       return 0;
 }
+
index 8f289b4865dd55c19ae968445ec7c5be9ed55cb4..3187440f96d7e59ee965e5067f5159f46309e191 100644 (file)
@@ -1,4 +1,5 @@
 //-----------------------------------------------------------------------------
+// Copyright (C) 2010 iZsh <izsh at fail0verflow.com>
 // Copyright (C) Merlok - 2017
 //
 // This code is licensed to you under the terms of the GNU GPL, version 2 or,
 #ifndef CMDHFLIST_H
 #define CMDHFLIST_H

-#include <stdlib.h>
-#include <stdint.h>
-#include <stdbool.h>
+extern int CmdHFList(const char *Cmd);

-typedef struct {
-       uint32_t uid;       // UID
-       uint32_t nt;        // tag challenge
-       uint32_t nt_enc;    // encrypted tag challenge
-       uint8_t nt_enc_par; // encrypted tag challenge parity
-       uint32_t nr_enc;    // encrypted reader challenge
-       uint32_t ar_enc;    // encrypted reader response
-       uint8_t ar_enc_par; // encrypted reader response parity
-       uint32_t at_enc;    // encrypted tag response
-       uint8_t at_enc_par; // encrypted tag response parity
-       bool first_auth;    // is first authentication
-       uint32_t ks2;           // ar ^ ar_enc
-       uint32_t ks3;       // at ^ at_enc
-} TAuthData;
-extern void ClearAuthData();
-
-extern uint8_t iso14443A_CRC_check(bool isResponse, uint8_t* data, uint8_t len);
-extern uint8_t mifare_CRC_check(bool isResponse, uint8_t* data, uint8_t len);
-extern void annotateIclass(char *exp, size_t size, uint8_t* cmd, uint8_t cmdsize);
-extern void annotateIso15693(char *exp, size_t size, uint8_t* cmd, uint8_t cmdsize);
-extern void annotateTopaz(char *exp, size_t size, uint8_t* cmd, uint8_t cmdsize);
-extern void annotateIso14443b(char *exp, size_t size, uint8_t* cmd, uint8_t cmdsize);
-extern void annotateIso14443a(char *exp, size_t size, uint8_t* cmd, uint8_t cmdsize);
-extern void annotateMifare(char *exp, size_t size, uint8_t* cmd, uint8_t cmdsize, uint8_t* parity, uint8_t paritysize, bool isResponse);
-extern bool DecodeMifareData(uint8_t *cmd, uint8_t cmdsize, uint8_t *parity, bool isResponse, uint8_t *mfData, size_t *mfDataLen);
-extern bool NTParityChk(TAuthData *ad, uint32_t ntx);
-extern bool NestedCheckKey(uint64_t key, TAuthData *ad, uint8_t *cmd, uint8_t cmdsize, uint8_t *parity);
-extern bool CheckCrypto1Parity(uint8_t *cmd_enc, uint8_t cmdsize, uint8_t *cmd, uint8_t *parity_enc);
-extern uint64_t GetCrypto1ProbableKey(TAuthData *ad);
-
-#endif // CMDHFLIST
+#endif // CMDHFLIST_H
index 8f3d8d2e5d08e40663f394a3f2e38e53ed3b87bd..d5b9c287a180553636e3454f361f55e74271880b 100644 (file)
@@ -18,7 +18,7 @@
 #include "smartcard.h"
 #include "comms.h"
 #include "protocols.h"
-#include "cmdhf.h"              // CmdHFlist
+#include "cmdhflist.h"
 #include "emv/apduinfo.h"       // APDUcode description
 #include "emv/emvcore.h"        // decodeTVL
 #include "crypto/libpcrypto.h"                 // sha512hash
index 79d8e0832665ff9244cf271e218316282c4f11ec..82b69f9d8307c6680530d4ed5c5f0a3a833cdb65 100644 (file)
@@ -234,6 +234,8 @@ NXP/Philips CUSTOM COMMANDS
 #define TOPAZ         3
 #define PROTO_MIFARE  4
 #define ISO_7816_4    5
+#define ISO_15693     6
+

 //-- Picopass fuses
 #define FUSE_FPERS   0x80
Impressum, Datenschutz
